Features:

  • MicroController based design
  • Upgradeable Bank interest Rate Display
  • 2″ size Dot Matrix LED type Bank Name Display
  • 1″ size 7 segment LED Display for interest rates
  • 1″ size 7 segment LED Display For Date and Time [ RTC based ]
  • 11 Rows and 2 Columns of 3 digits display
  • 11 Rows and single column of 4 digits display
  • Manual switches to update of interest rates time and Date
  • IR Remote for wireless update of values [ Optional ]
  • Update through PC Serial / USB Ports using customized software [ Optional ]
  • The bank Name Display of 2″ Dot matrix LED display can be used as moving display to advertise [ Optional ]
  • Easy to install and no maintenance except dust cleaning on the outside of the Unit
  • SMPS power supply: Working from 90V to 270V AC
  • Super bright LED Display: Clarity on normal lighting condition
Specifications
Input Voltage 90-270V AC
Operating Voltage 5V DC / 5 AMPS
Operating Current 3 Amps @ 5V DC
Power consumption 40 watts @ 230 V AC
Display Size Header 2″ in Height 5×7 Dot Matrix LED Display
Display Size Value 1″ in Height 7 segment LED Display
Dimension 900mm x 450 mm x 100mm
Panel type Powder coated (CRCA) and weather Proof
Operating temperature 0° to 50° C

*Specifications are subject to change without notice
